Quick Details

  • Light Source: LED
  • Item Type: High Bay Lights
  • LED Light Source: CREE
  • Warranty(Years): 3
  • Input Voltage(V): 100~277VAC
  • Lamp Power(W): 200
  • Lamp Luminous Flux(lm): 23000
  • Lamp Luminous Efficiency(lm/w): 100
  • CRI (Ra>): 70
  • Color Temperature(CCT): Cool White
  • Working Temperature(℃): -40 - +55
  • Working Lifetime(Hour): 100000
  • Lamp Body Material: Aluminum Alloy
  • IP Rating: IP66
  • Certification: CCC, CE, RoHS
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: Tormin
  • Model Number: ZY8502
  • Frequency: 50Hz/ 60Hz
  • Rated Power: 60w 80w 100w 120w 150W 200W
  • Material: Aluminium alloy, tempered glass
  • Net Weight: 4.8Kg
  • Dimension: 300* 235mm(100~200W)

Packaging & Delivery

Packaging Details 1 piece per carton,300* 300* 235mm(100~200W),N.W.: 4.8kg
Delivery Time Shipped in 10 days after payment

IP66 200w floodlight easy maintenance industry LED high bay industrial light



Model: ZY8502 Series

Product Description

IP Code: IP66

Ambient temp.: -40°C to +55°C







Application





1. The product is suitable for use in power station, steel industry, workshop and other places



Characteristics



1. Radiators adopt comprehensive self-loop design, long-term suitable for operating environment with high temperature and high humidity. Upper and lower ventilation fin structure, no dust.
2. Variety of light distribution, variety of installation types, an effective solution to beautify workshop and device platform.
3. It adopts imported light source, no dark zone in light spot, no ghosting, can save 60% or more on energy than the Metal Halide Lamp.
4. AC and DC wide voltage constant power supply, power factor up to 0.98.
5. LED high bay light fixture can achieve quickly scene replacement of light source and electrical without welding.
6. According to user needs,achieve a variety of intelligent control.





Main specification

ItemTechnical Parameters
Input Voltage100~277VAC
Frequency50Hz/ 60Hz
Light sourceLED
Life time100000h
CRI Ra 70(80 Optional)
CCT3000K/ 4000K/ 5000K
Dimension 230* 175mm(60W)
230* 180mm(80W)
300* 235mm(100~200W)
Net Weight4.8Kg(Max)



Ordering reference



Ordering referenceWattageLight outputSpace height ratio0.4~1.75Mounting heightEquivalent to
Metal Halide Lamp
ZY8502-L6060W>7600lm0.4~1.758~10m150W
ZY8502-L8080W>9000lm8~12m175W
ZY8502-L100100W>11200lm250W
ZY8502-L120120W>12900lm10~15m>250W
ZY8502-L150150W>16400lm400W
ZY8502-L200200W>23000lm400W~600W
Note: The above model numbers are ring mounted light, pole mounted lights are required to plus "P" after the model numbers (as ZY8502P-L150-100 °)

Packaging & Shipping

1 piece per carton,300* 300* 235mm(100~200W),N.W.: 4.8kg


Our Services
  • reply you within 24h
  • professional sales and customer-servicedept.both work for you,high efficiency of communication
  • report order status every day
  • reliable after-sale service
  • OEM available

 Dialux Solution,telling you which iem,which power,how many pcs,which beam angle suitable

  1. dialux to check suitable item;
  2. recommend to customer;
  3. project done

Company Information




FAQ

Q: How many lumen are these? How long can they use?

A: The form below for your reference:




Q: What places do your LED High Bay Light applicable to?

A:It is ideal to be used in power station, petrochemical industry,metallurgy and other indoor and outdoor places.



Q:Can you introduce briefly for your LED high bay light? Are they unique,different from other suppliers'?

A: Tormin's  Industrial High Bay Light are designed and patented independently by Zhejiang Tormin electrical Co.,Ltd. We ensure quality by using CREE LED clip, aluminium housing and tempered glass. We ensure safety by strict testing and inspection.
